IRRIGABRAS HOSE REEL IRRIGATION
TECHNICAL SPECIFICATION OF C90 MODEL
​
HOSE REEL IRRIGATION:
PE Hose diameter:
PE Hose maximum length:
Flow (min/max):
Inlet pressure (min/max):
System Capacity:
​
​
C 90
90 mm
350 m
30 / 54m3 /h
5.0 bar / 10.0 bar
34 ha
ADVANTAGES OF IRRIGABRAS HOSE REEL IRRIGATION
​
-
Simple and reliable to operate
-
The reel can turn 360
-
The nozzle gun is adjustable for height and width.
-
High Strength Structure, heat galvanized and protected for maximum protection.
-
With Easy rain 3, you can program and control the winding speed of the hose during the entire irrigation cycle
-
With a 4 or 6 speed gearbox, with out pulleys and belts – It offers lower power consumption, a faster hose winding speed and more operator safety.
-
After sales support of TRACTORCO
